The NOR Gate has 3 Input sides and 1 Output side. It will output power if it doesn't receive any power from any Input side. It won't output power if it receives power from at least one of its Input sides. The image on the right shows the 3 Inputs that are linked together. Similar gates are the XOR Gate, the OR Gate and the XNOR Gate.


Crafting GUI.png

Stone Wafer

Stone Wire

Stone Wafer

Stone Anode

Stone Cathode

Stone Wire

Stone Wafer

Stone Wire

Stone Wafer

NOR Gate


The NOR Gate is used for circuits where multiple power sources can unpower the same thing, such as 3 buttons placed around a house, that cause a piston to open the entrance when pressed. When using a NOR Gate, using an Invertor is no longer necessary in combination with an OR Gate. It will give the same outcome, however, the NOR Gate gives the advantage that it needs little space, less material and is less complicated.
2012-07-19 15.08.05

At least one input must be active to stop the output power.

Logic table

A B C Output
0 0 0 1
0 0 1 0
0 1 0 0
0 1 1 0
1 0 0 0
1 0 1 0
1 1 0 0
1 1 1 0

0's represent an inactive signal. 1's represent an active signal.

Note that the outcome is equal to the Output of the NOR Gate.
